Digimatic Concrete Impermeabilty Apparatus Manufacturer,Supplier and Exporter in India
Product Code : TVT-CTE-10496
The Digimatic Concrete Impermeability Apparatus determines the depth to which water penetrates hardened concrete under pressure, using a fully automatic digital control panel with a high-precision pressure transducer for fine, precise pressure control across 6 test chambers.
How It Works
Concrete cube, cylinder, or prismatic specimens (up to 200 x 200 x 200mm) are located between quick-clamping chambers and sealed with special circular gaskets. Water is then applied under controlled pressure — up to 20 MPa (200 bar) — to one face of each specimen for a specified period, driven by the built-in air-pressure compressor and water tank system. After the test period, each specimen is split open and the maximum depth of visible water penetration is measured directly, giving a measure of the concrete's resistance to water penetration (a key durability indicator).
Technical Specifications
| Parameter | Specification |
|---|---|
| Standard Test Chambers | 6 Chambers |
| Maximum Specimen Size | 150mm and 200mm cube specimens, Ø100 x 200mm and Ø150 x 300mm cylinder specimens |
| Maximum Pressure | 20 MPa (200 bar) |
| Dimension | 770 x 1050 x 1450 mm |
| Weight | 150 kg |
| Power | 220V, 1 Ph, 50/60 Hz, 375 W |
| Note on chamber upgrade | The standard configuration has 6 chambers; upgrade options are available on request. |
Applications
Used to determine the depth of water penetration into hardened concrete under pressure, per EN 12390-8, an important durability indicator used to assess concrete's resistance to water and chloride ingress in structures exposed to water, marine, or aggressive environments.
Related Products & Category
Listed under Concrete Testing Equipments. Related products: Welded Frame Compression Machine 3000kN and Cast Iron Cylinder Mould.
Frequently Asked Questions
What does this apparatus actually measure?
The depth to which water penetrates into a concrete specimen under sustained pressure (up to 20 MPa), measured after splitting the specimen open — a key indicator of concrete durability and resistance to water/chloride ingress, per EN 12390-8.
What specimen sizes and shapes are accepted?
150mm and 200mm cubes, and Ø100 x 200mm or Ø150 x 300mm cylinders, across 6 test chambers running simultaneously.
Can this apparatus be upgraded to test more specimens at once?
Yes, an upgrade from the standard 6-chamber configuration is offered. Tell us how many specimens you need to test at once and the quotation will confirm the chamber count.
