Digimatic Load Cell 300kN Manufacturer,Supplier and Exporter in India
Product Code : TVT-CTE-10510
The Digimatic Load Cell 300kN is a digital-readout load and force verification device consisting of a sensitive steel-block strain element housed in a protective sheathing, used for calibrating compression testing machines at the lower end of the capacity range.
How It Works
As load is applied through the compression testing machine under calibration, strain in the sensitive steel-block element is transmitted to an amplifier, which converts it into a digital load reading. Comparing this reading against the testing machine's own indicated load verifies the machine's force accuracy across its working range.
Technical Specifications
| Parameter | Specification |
|---|---|
| Capacity | 300 x 0.01 kN |
| Load Cell Dimension | Ø140 x 180(H) mm |
| Working Temperature | 0 – 45°C, Moisture up to 80% RH |
| Accuracy | Class ±1% |
| Approx. Weight | 19 kg |
| Power | NiCd battery, AC adaptor as charging source |
Applications
Used for load and force verification/calibration of compression testing machines per ASTM E4 (Standard Practices for Force Verification of Testing Machines) and ISO 376 (calibration of force-proving instruments), suited to calibrating lower-capacity compression and flexural machines.
Related Products & Category
Browse the full Concrete Testing Equipments range, or see Digimatic Load Cell and 100kN Hydraulic Flexural Frame.
Frequently Asked Questions
What is the difference between this and the standard Digimatic Load Cell?
This 300kN unit is intended for calibrating lower-capacity testing machines, while the standard Digimatic Load Cell has a 2000kN capacity for higher-capacity machines; both share the same accuracy class, working temperature range, and power supply.
What is the capacity of this load cell?
300kN, read in 0.01kN increments.
Is there a size difference between the 300kN and 2000kN load cells?
The manufacturer’s published dimensions show this 300kN unit as marginally larger than the higher-capacity 2000kN model, which is not the usual pattern for load cells — confirm exact dimensions with Tvet Equipments if platen clearance is a concern.
