Air Entrainment Meter (7 Litres) Manufacturer,Supplier and Exporter in India
.jpg)
Product Code : TVT-CTE-10499
The Air Entrainment Meter (7 Litres) determines the air content of fresh concrete by equalising a known volume of air in a pressure chamber against the sample, using an aluminium cast vessel designed for easy field disassembly so worn or damaged parts can be replaced on site.
How It Works
A 7-litre sample of fresh concrete is sealed in the cast-aluminium vessel; a known air pressure is introduced into a reference chamber and equalised against the sample chamber, and the resulting pressure drop is read on the gauge as a percentage air content. The vessel's disassembling design lets worn seals and internal parts be replaced in the field rather than requiring the unit be returned to the manufacturer.
Technical Specifications
| Parameter | Specification |
|---|---|
| Sample Capacity | 7 litres |
| Gauge Graduations | 0.1% divisions up to 6%, 0.2% divisions from 6% to 10% |
| Approx. Product Weight | 7.5 kg |
| Approx. Total Weight (with case) | 21 kg |
| Product Dimension | Ø250 (D) x 500 (H) mm |
| Case Dimension | 660 (L) x 450 (W) x 310 (H) mm |
Applications
Used to determine the air content of fresh concrete per ASTM C231 and EN 12350-7 (pressure method), typically for verifying air entrainment in concrete intended for freeze-thaw exposure or specific workability/durability requirements.
Related Products & Category
Listed under Concrete Testing Equipments. Related products: Air Entrainment Meter 7 Litres (E-Version) and Air Entrainment Meter (8 Litres).
Frequently Asked Questions
What sample size does this meter use?
7 litres of fresh concrete.
What makes this unit field-serviceable?
The aluminium cast vessel is designed to be disassembled on site, so worn or damaged internal parts and seals can be replaced without returning the unit to the manufacturer.
Request a Quote
For a price on the Air Entrainment Meter (7 Litres), send us the quantity, the standard or test method it is for and where it should be delivered. Send an enquiry to Tvet Equipments.
