Surface Soil Sample Apparatus Manufacturer,Supplier and Exporter in India
Product Code : TVT-STE-10574
The Surface Soil Sample Apparatus is a driven-tube sampler used to take samples of compacted fill or undisturbed soil at the ground surface, and to evaluate the density of compaction at that surface.
How It Works
A thin-walled sampling tube is driven into the compacted fill or undisturbed soil using a drop hammer of matched weight, recovering a sample with minimal disturbance for density evaluation and further laboratory testing. Tvet Equipments offers two set sizes, each paired with a proportionate drop hammer so that driving energy suits the tube diameter.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model 1 – Dimension | Ø73 x 66 (L) mm |
| Model 1 – Approx. Weight | 10 kg |
| Model 1 – Drop Hammer | 5 kg |
| Model 2 – Dimension | Ø100 x 130 (L) mm |
| Model 2 – Approx. Weight | 16 kg |
| Model 2 – Drop Hammer | 10 kg |
Applications
This surface sampler is used for near-surface density and compaction evaluation of fill and undisturbed soils, aligned with the core-cutter/drive-sampler family of in-situ density methods covered by IS 2720 (Part 29) and ASTM D2937: Standard Test Method for Density of Soil in Place by the Drive-Cylinder Method, with the general practice for recovering samples for further examination following ASTM D1587: Standard Practice for Thin-Walled Tube Sampling of Soils. It is used to quickly confirm that near-surface fill has been placed and compacted to the required density.
Related Products & Category
Listed under Soil Testing Equipment. Related products: Core Cutter Set and Sand Density Cone Apparatus.
Frequently Asked Questions
Why does this sampler come in two sizes?
The two set sizes (73 mm and 100 mm diameter) suit different fill materials and sample volumes, each paired with a proportionate drop hammer for suitable driving energy.
What is the drop hammer used for?
The drop hammer drives the sampling tube into the compacted fill or undisturbed soil, recovering the sample with minimal disturbance.
What is this apparatus used to evaluate?
It is used to evaluate the density of compaction of fill or undisturbed soils at the ground surface.
Request a Quote
To get a quotation for the Surface Soil Sample Apparatus, tell us the test standard you work to, the quantity and the delivery location. Request a quote from Tvet Equipments.
