Shrinkage Mould 75 X 75 X 300mm Manufacturer,Supplier and Exporter in India
Product Code : TVT-CTE-10494
The Shrinkage Mould 75 x 75 x 300mm is a polished-surface mild-steel mould used to cast prism specimens for determining the linear (drying) shrinkage of concrete over time.
How It Works
A concrete prism (75 x 75 x 300mm) is cast in the mould with a measuring stud or gauge point embedded at each end. After demoulding, the specimen's length is measured against a length comparator at set time intervals as it dries and shrinks, and the change in length relative to the initial reading is calculated as a percentage — the linear shrinkage. The mould's polished-surface mild-steel construction gives a smooth, true casting surface that helps produce a specimen with accurately parallel, plane ends.
Technical Specifications
| Parameter | Specification |
|---|---|
| Mould Dimension | 347 (L) x 97 (W) x 86 (H) mm |
| Specimen Dimension | 75 x 75 x 300 mm |
| Material | Polished-surface mild steel |
| Approx. Weight | 7.5 kg |
Applications
Used to cast standard prism specimens for determining the linear (drying) shrinkage of concrete per ASTM C157 and IS 516, an important property for assessing crack-risk and long-term dimensional stability of a concrete mix.
Related Products & Category
The Shrinkage Mould 75 X 75 X 300mm is part of our Concrete Testing Equipments range. Other products in this range include Cast Iron Beam Moulds and L-Box.
Frequently Asked Questions
What does this mould produce a specimen for?
A 75 x 75 x 300mm concrete prism used to measure linear (drying) shrinkage over time, per ASTM C157/IS 516.
How is shrinkage actually measured on the cast specimen?
The demoulded prism’s length is measured against a length comparator at set time intervals as it dries, and the change relative to the initial length is expressed as a percentage shrinkage.
Why is linear shrinkage testing important for concrete mix design?
Excessive drying shrinkage increases the risk of cracking in hardened concrete, so shrinkage testing helps assess and control this risk when qualifying a mix design, particularly for slabs and other restrained elements.
Request a Quote
To get a quotation for the Shrinkage Mould 75 X 75 X 300mm, tell us the test standard you work to, the quantity and the delivery location. Request a quote from Tvet Equipments.
