Product Code : TVT-STE-10620
The Rockwell Hardness Tester (Analogue Indicator) determines the Rockwell hardness of metallic materials by measuring the depth of penetration of an indenter under a major test load, read directly off an analogue dial.
How It Works
A diamond cone or hardened steel ball indenter is first pressed into the sample under a small preliminary (minor) load to seat it, then a larger major load is applied and subsequently removed while the minor load is held; the permanent increase in indentation depth caused by the major load is read directly off the analogue dial indicator in Rockwell hardness units, without any separate diameter measurement being required.
Technical Specifications
| Parameter | Specification |
|---|---|
| Test Forces | 588.4 N (60 kgf), 980.7 N (100 kgf), 1.171 kN (150 kgf) |
| Indicator Scale | C: 0–100, B: 30–130 |
| Hardness Test Dimensions (L x W x H) | 457 x 240 x 629 mm |
| Approx. Weight | 75 kg |
Applications
Rockwell hardness testing is governed by ASTM E18: Standard Test Methods for Rockwell Hardness of Metallic Materials and IS 1586: Method for Rockwell Hardness Test for Metallic Materials. Its standard 60/100/150 kgf test forces and B/C scale readout are used across a wide range of structural and reinforcement steels for quick, direct hardness verification without needing a separate indentation-diameter measurement.
Related Products & Category
The Rockwell Hardness Tester (Analogue Indicator) is part of our Steel Testing Equipments range. Other products in this range include Brinell Hardness Tester and Non Metallic Material Extensometer.
Frequently Asked Questions
How does the Rockwell test read hardness?
It reads hardness directly from the depth of indenter penetration under a major test load, shown on an analogue dial, rather than by measuring an indentation diameter.
What test forces does this tester use?
It uses the standard Rockwell test forces of 60 kgf, 100 kgf, and 150 kgf, with B and C scale readout.
Request a Quote
To get a quotation for the Rockwell Hardness Tester (Analogue Indicator), tell us the test standard you work to, the quantity and the delivery location. Request a quote from Tvet Equipments.
