Product Code : TVT-CMTE-10396
Low Strength Compression
User can request any maximum compression force (Between 300 to 1000 kN).
This semi-automatic compression machine special designed for specimen such as low strength concrete,brick,mortar and etc.
Unique Feature :-
- Rapid approach system for time saving.
- Front and side safety enclosed.
- Grade 1.0 compression accuracy.
- 5 elements injection hydraulic pump.
- High tensile pre-stress 4 column frame.
- Loading speed control knob.
Digimatic multi function controller :-
-Force value in kN & Mpa
-Max. force hold facility with real time force vs time graph display
-Multiple testing program can be selected
-Auto result saving up to 450 specimen
-RS 232 port for instand result printing (Mini printer c/w cable need order separately)
-115 x 65 mm high resolution LED screen
Technical
Specifications:
|
Capacity
& Sensitivity |
300
till 1000kN (Upon request by user) x 0.1 kN |
|
Max
Vertical Clearance |
228
mm |
|
Max.
Horizontal Clearance |
240
mm |
|
Compression
Platen Size |
Top
: Ø220 mm, Bottom : 220 mm x 250 mm |
|
Piston
Ram Diameter & Travel |
200
mm x 80 mm |
|
Approx.
Dimension (mm) |
355(L)
x 885 (W) x 1210 (H) |
|
Approx.
Weight |
600
kg |
|
Power |
AC
220 V , 1ph, 0.75kW,4.9 A, 50/60 Hz |
