Touch Screen Compression Machine 3000kN Manufacturer,Supplier and Exporter in India
Product Code : TVT-CTE-10430
Newly upgraded model with brand new outlook.
Old AC motor replaced by new imported DC motor for more durability, low noise pollution, low oil temperature & low power consumption.
Features:-
Auto result saving up to 450 specimens
Simple operation system
Dual channels ready for compression & flexural
Less vibration & noise
Piston travel switch
Energy saving
Additional Features:-
Upgraded fully covered safety enclosed
USB port to export test result
Extended base frame for comfortable operation level
Touch Screen Smartz Controller V1.1
Real time speed indicator bar for better current speed reference for better control.
Manual loading & conditional automatic loading for compression machines with suitable DC motor control system.
Automatic conversion from kN to Mpa according to the chosen sample types.
Clear, easy to read, sensitive & large LCD touch screen display of 155mm(W) x 85 mm(H)
Maximum force hold facility with real time Force vs Time graph display.
User input test number, age, weight & density for complete sample information.
Technical
Specifications :
|
Max.
Vertical Clearance
|
370
mm
|
|
Max.
Horizontal Clearance
|
320
mm
|
|
Capacity
|
3000
kN
|
|
Low
Range Sensitivity
|
0
- 999 x 0.1 kN
|
|
High
Range Sensitivity
|
1000
- 3000 x 1 kN
|
|
Compression
Platen Diameter
|
295
mm
|
|
Piston
Ram Diameter
|
290
mm
|
|
Piston
Ram Travel
|
50
mm
|
|
Column
Diameter
|
73
mm
|
|
Accuracy
|
Class
1
|
|
Product
Dimension (mm)
|
1020
(L) x 650 (W) x 1300 (H)
|
|
Packing
Dimension (mm)
|
1065
(L) x 700 (W) x 1450 (H)
|
|
Approx.
Product Weight
|
905
kg
|
|
Approx.
Packing Weight
|
972
kg
|
|
Power
|
240
V, 750 W, 5 Amp, 50 / 60 Hz, 1 ph
|
