Pull Out Tester 50kN Manufacturer,Supplier and Exporter in India
Product Code : TVT-CTE-10488
The Pull Out Tester 50kN is a portable digital pull-out testing unit for anchor rods, steel rods, expansion bolts, and other anchoring devices, suitable for rebar samples up to 12mm diameter, with data storage for repeated site or lab use.
How It Works
A hand pump drives the 5-ton-capacity hydraulic hollow cylinder to apply a steadily increasing pull-out force to the anchored bar or bolt through a matched specimen wedge, while the digital gauge displays load with 0.001 kN resolution. Test results are stored in the unit's internal memory (up to 500 groups) with a display duration of up to 200 hours, letting multiple tests be logged and reviewed without needing to record each reading manually on site.
Technical Specifications
| Parameter | Specification |
|---|---|
| Max. Capacity & Resolution | 50 kN x 0.001 kN |
| Piston Travel | 50 mm |
| Piston Hollow Diameter | 18 mm |
| Data Storage | 500 Groups |
| Display Duration | 200 Hours |
| Case Dimension | 430 (L) x 350 (W) x 155 (H) mm |
| Approx. Weight | 25 kg |
| Specimen Wedges Supplied | 6mm, 8mm, 10mm, 12mm |
Applications
Used to determine the bond/anchorage strength between anchored reinforcing steel bar (rebar), anchor rods, or expansion bolts and concrete, and to check anchorage performance in-situ, using the pull-out method of ASTM E488/E488M (strength of anchors in concrete), for rebar and anchor diameters up to 12mm.
Related Products & Category
The Pull Out Tester 50kN is part of our Concrete Testing Equipments range. Other products in this range include Digital Pull Out Tester and Pull Out Test Apparatus.
Frequently Asked Questions
What size rebar or anchors can this tester handle?
Up to 12mm diameter, using the supplied specimen wedges (6mm, 8mm, 10mm, 12mm).
How many test results can the unit store?
Up to 500 groups of test data, with a display duration of up to 200 hours.
How does this differ from the Digital Pull Out Tester?
This is a lighter, lower-capacity (50kN) unit aimed at smaller anchors and rebar up to 12mm; the Digital Pull Out Tester covers a wider capacity range (100kN-1000kN) for larger rebar diameters up to 40mm.
Request a Quote
To get a quotation for the Pull Out Tester 50kN, tell us the test standard you work to, the quantity and the delivery location. Request a quote from Tvet Equipments.
