Mild Steel Cube Moulds Manufacturer,Supplier and Exporter in India
Product Code : TVT-CTE-10480
Mild Steel Cube Moulds are gang-type concrete cube moulds, available in 3-gang and 4-gang configurations at both 100mm and 150mm cube sizes, letting multiple cube specimens be cast from a single mould assembly at once.
How It Works
Each gang mould holds several individual cube cavities (3 or 4, depending on configuration) side by side within one rigid mild-steel frame, so a full set of replicate cube specimens for a single concrete batch can be cast in one filling and compaction operation rather than one mould at a time. After curing, the gang frame is opened and the individual cubes are demoulded.
Technical Specifications
| Parameter | Specification |
|---|---|
| 100mm Mild Steel 3-Gang Cube Mould | 415 x 205 x 120 mm, 13.0 kg |
| 150mm Mild Steel 3-Gang Cube Mould | 605 x 280 x 180 mm, 33.5 kg |
| 100mm Mild Steel 4-Gang Cube Mould | 600 x 200 x 120 mm, 25.0 kg |
| 150mm Mild Steel 4-Gang Cube Mould | 730 x 230 x 160 mm, 47.0 kg |
Applications
Used to cast multiple standard 100mm or 150mm concrete cube specimens at once for compressive strength testing per ASTM C31, IS 516, and EN 12390-1, improving throughput for labs that routinely cast several cubes per concrete batch.
Related Products & Category
Browse the full Concrete Testing Equipments range, or see Cast Iron Cube Mould (L-Shape) and Mild Steel Beam Moulds.
Frequently Asked Questions
What does "gang mould" mean?
A gang mould holds several individual cube cavities in one rigid frame, letting multiple replicate cube specimens be cast from a single batch of concrete in one operation.
What is the difference between the 3-gang and 4-gang versions?
The 3-gang mould casts 3 cubes at once and the 4-gang mould casts 4 cubes at once, in the same 100mm or 150mm cube sizes — the 4-gang version is larger and heavier for the higher throughput.
How does this differ from the single-cavity Cast Iron Cube Mould (L-Shape)?
This is a mild-steel, multi-cavity gang mould for casting several cubes at once; the L-Shape mould is a single-cavity cast-iron mould casting one cube per mould per operation.
Request a Quote
For a price on the Mild Steel Cube Moulds, send us the quantity, the standard or test method it is for and where it should be delivered. Send an enquiry to Tvet Equipments.
