Galvanized Curing Tank With Drain Valve Manufacturer,Supplier and Exporter in India
Product Code : TVT-CTE-10458
The Galvanized Curing Tank With Drain Valve is a galvanized-steel water curing tank for concrete test specimens, available in a range of sizes holding from around 60 to over 500 standard 150mm cubes, with a drain valve for easy water changeover and cleaning.
How It Works
Concrete cubes, cylinders, or beams are fully submerged in the tank, which is filled with clean water (often lime-saturated water per the governing standard) maintained at the specified curing temperature, keeping specimens continuously moist until their test age. The drain valve allows the tank to be emptied for water renewal and cleaning without tipping or lifting the tank. Tvet Equipments offers this tank in 6 sizes, sized by their approximate 150mm cube holding capacity, to suit laboratories of different throughput.
Technical Specifications
| Parameter | Specification |
|---|---|
| 1600 x 800 x 700 mm | Approx. 144-200 nos. 150mm cubes |
| 850 x 700 x 550 mm | Approx. 60 nos. 150mm cubes |
| 1220 x 1220 x 550 mm | Approx. 108-192 nos. 150mm cubes |
| 1440 x 1220 x 1000 mm | Approx. 288-432 nos. 150mm cubes |
| 2000 x 1550 x 550 mm | Approx. 297-390 nos. 150mm cubes |
| 2650 x 1300 x 850 mm | Approx. 525-680 nos. 150mm cubes |
Applications
Used for the standard water curing of concrete cube, cylinder, and beam specimens prior to strength testing, per ASTM C511 and IS 516, which specify moist-curing conditions and duration for concrete test specimens.
Related Products & Category
The Galvanized Curing Tank With Drain Valve is part of our Concrete Testing Equipments range. Other products in this range include Plastic Curing Tank and Welded Frame Compression Machine 3000kN.
Frequently Asked Questions
What is the purpose of the drain valve?
It allows the tank to be emptied for water renewal and cleaning without tipping or lifting the tank.
How many 150mm cubes can the largest tank hold?
The largest listed size (2650 x 1300 x 850mm) holds approximately 525-680 nos. of 150mm cubes.
What curing conditions does this tank support?
Full water immersion curing per ASTM C511/IS 516, which specify the curing water quality and temperature and the minimum curing duration before testing.
Request a Quote
To get a quotation for the Galvanized Curing Tank With Drain Valve, tell us the test standard you work to, the quantity and the delivery location. Request a quote from Tvet Equipments.
