Flexural Machine Manufacturer,Supplier and Exporter in India
Product Code : TVT-CTE-10464
Flexural Test
Overall structure are rigid & compact.
Using DC motor for more durability, low noise pollution, low oil temperature & low power consumption.
Our flexural frame has been designed to achieved minimum deflection at maximum pressures resulting in very high accuracy.
Technical
Specifications :
|
Max.
Capacity
|
100 kN x 0.1 kN Sensitivity
|
150 kN x 0.1 kN Sensitivity
|
|
Load
Sensor Capacity
|
30 kPa
|
50 kPa
|
|
Roller
Size (mm)
|
28 Dia. x 160 mm Lg.
|
|
Max.
Vertical Clearance
|
165 mm
|
|
Max.
Horizontal Clearance
|
160 mm
|
|
Max.
Piston Travel
|
80 mm
|
|
Loading
span
|
100 mm / 150 mm or Single
|
|
Support
span
|
300 mm / 450 mm
|
|
Frame
Dimension
|
300 (L) x 340 (W) x 1108 (H)
|
|
Console
Unit Dimension
|
350 (L) x 400 (W) x 1158 (H) mm
|
|
Power
|
220 V, 2.5 Amp, ½ ph, 50 / 60 Hz
|
|
Approx.
Product Weight
|
261 kg
|
260 kg
|
