Automated Asphalt Cutting Machine Manufacturer,Supplier and Exporter in India
Product Code : TVT-BATE-10356
Mixing Of Elements
specimen into asphalt mixture Mechanical testing required for other sizes, with high precision, automated operation, safe and reliable features.
It also can be based on user needs to install other clamping accessories, for others type of material such as terrazzo, natural stone, concrete products, ceramics, refractory bricks and other non-metallic materials and pipe.
Automated Asphalt Cutting Machine is a fully enclosed automatic specimen cutting machine for cutting the standard asphalt mixture cylindrical (Φ100 ~ Φ155mm) or 300 mm x 300 mm plate
This machine is fully computerized system with touch screen control panel,it also come with automated specimen clamping and sawing system for fast,accurate cutting all kind of specimen.
Technical
Specifications:
Spindle
Speed
1450
RPM
Cutting
Speed
0
- 999 mm/min
Cooling
Pump Flow
4
L / min
Maximum
Cutting Thickness
150
mm
Maximum
Cutting Width
-
300 mm Automatic Fixture -
400 mm no Automatic Fixture Installed
Blade
Diameter
500
mm
Operation
Pressure
0.6
~ 0.8 Mpa/20 litres (Built In)
Pneumatic
Claimping Force : *Round
Specimen *Slab
Specimen
