Thermostatic Asphalt Planetary Mixer Manufacturer,Supplier and Exporter in India
Product Code : TVT-BATE-10372
Bituminous Mixing
The unit comes with PID temperature control unit with digital display.
The mixer mixed homogeneous, uniform efficient fast mixture action.
They are of easy and practical utilization suite for laboratory purpose.
This mixer featuring 20 litres capacity.
The mixer has been designed for bituminous homogenous mixing, consists essentially in a horizontal tilting thermostatic drum.
Tilting drum is 130° angles. The mixing chamber is heated by dielectric chamber with diathermic thermostatic control.
This large capacity heavy duty mixer designed to mix bituminous sample for tensile splitting test, compaction test, marshall and other test where uniformity is required.
The bituminous mixture can be easily discharge by the total turnover of the mixing chamber.
Technical
Specifications:
Mixing
Capacity
10
Litres
Drum
Capacity
20
Litres
Planetary
Speed
45
±5 RPM
Spindle
Speed
75
±5 RPM
Temperature
Range
Ambient
- 250°C (Adjustable)
Temperature
Accuracy
±3Ëšc
Setting
Timer
1
- 999 Seconds
Mixing
Speed (RPM)
Planetary
: 0-55 , Spindle : 0-92
Overall
Dimension
1200
(L) x 550 (W) x 1320 (H) mm
Packing
Dimension
1300
(L) x 650 (W) x 1520 (H) mm
Drum
Heating
3000
W
Approx.
Weight
196
kg
Packing
Weight
216
kg
Power
220
V, 1 ph, 50 / 60 Hz, 15 amp Motor
: 750 W, 1hp, 350 W, 1/2 hp
