Auger Power Head Manufacturer,Supplier and Exporter in India
Product Code : TVT-STE-10563
The Auger Power Head is an engine-driven drive unit that powers a hand auger for faster, less labour-intensive soil boring during site investigation, designed for single-operator use.
How It Works
A compact two-stroke engine drives the auger head through a gearbox, allowing one operator to bore holes for soil sampling and identification without manual turning effort. All engine controls are grouped together for single-hand operation, and the unit is built around a chrome-lined cylinder with a forged-steel drive shaft and connecting rod for durability under repeated site use. The auger flight/bit itself is supplied separately and is selected to suit the required borehole diameter and soil type.
Technical Specifications
| Parameter | Specification |
|---|---|
| Piston Displacement | 52 cc |
| Engine | 2.5 kW two-stroke petrol engine |
| Fuel | Petrol/oil fuel mixture (2-stroke) |
| Fuel Capacity | 900 ml |
| Operation | Single operator |
| Max. Drill Diameter | 200 mm |
| Approx. Weight | 12 kg (excluding auger) |
| Dimension | 550 (L) x 400 (W) x 280 (H) mm (excluding auger) |
| Note | Auger head/flight supplied separately and ordered to suit required diameter |
Applications
The Auger Power Head is used to mechanise hand-auger boring for disturbed soil sampling and site investigation, complementing the manual method covered by ASTM D1452: Standard Practice for Soil Investigation and Sampling by Auger Borings and IS 1892: Code of Practice for Subsurface Investigation for Foundations. It speeds up borehole advancement in accessible ground where a full drilling rig is not warranted.
Related Products & Category
The Auger Power Head is part of our Soil Testing Equipment range. Other products in this range include Hand Auger Apparatus and Prospecting Kit.
Frequently Asked Questions
Is the auger bit included with the power head?
No, the auger head/flight is ordered separately and selected to match the required borehole diameter and soil conditions.
How deep or wide can this unit drill?
It supports drilling up to 200 mm diameter; achievable depth depends on the auger flight used and ground conditions.
Can one person operate this equipment alone?
Yes, it is purpose-designed for single-operator use, with engine controls grouped together for convenient one-hand operation.
Request a Quote
For a price on the Auger Power Head, send us the quantity, the standard or test method it is for, your mains supply and where it should be delivered. Send an enquiry to Tvet Equipments.
