Digimatic Compression Machine 2000kN Manufacturer,Supplier and Exporter in India
Product Code : TVT-CTE-10431
Compression & Flexural
New digimatic compression machine are special designed extremely strong and oversized to grant high rigidity and stability during testing.
With a fixed upper head carring a ball-seated platen and base platen with 150 mm cube centering guide pin.
Unique Feature: -
Rapid approach system for time saving
Grade 1.0 compression accuracy
Piston anti-over travel limit switch
Front and side safety enclosed
Digimatic multi-function controller: -
Max. force hold facility with real time force vs time graft display
Multiple testing program can be selected
Auto result saving up to 450 specimens
Force value in kN & Mpa
RS 232 port for instant result printing (Mini printer c/w cable NEED order separately)
115 x 65 mm high resolution LED screen
Technical
Specifications :
|
Max.
Vertical Clearance
|
400
mm
|
|
Max.
Horizontal Clearance
|
285
mm
|
|
Capacity
|
2000
kN
|
|
Low
Range Sensitivity
|
0
- 999 x 0.1kN
|
|
High
Range Sensitivity
|
1000
- 2000 x 1kN
|
|
Compression
Platen Diameter
|
216
mm
|
|
Piston
Ram Diameter
|
250
mm
|
|
Piston
Ram Travel
|
50
mm
|
|
Column
Diameter
|
65
mm
|
|
Product
Dimension (mm)
|
360
(L) x 950 (W) x 1330 (H)
|
|
Approx.
Product Weight
|
625
kg
|
|
Power
|
AC220
V,1 ph,4.9 amp,50/60 Hz,
|
