Aggregate Shape Gauge Manufacturer,Supplier and Exporter in India

Aggregate Shape Gauge

Product Code : TVT-ARTE-10327

The Aggregate Shape Gauge from Tvet Equipments measures the shape factor of aggregate particles, a quick hand-held check used alongside sieve-based elongation and flakiness testing.

How It Works

Individual aggregate particles are placed against the gauge's calibrated slots; a particle that passes through a given slot is classified accordingly, and the pass/fail pattern across the sample is used to compute the aggregate's shape factor.

Technical Specifications

ParameterSpecification
Dimension160(L) x 320(W) mm
Approx. Weight500 g
Tolerance/Limit (L/E)± 0.05
Scale Sensitivity0.05 mm

Applications

Shape-factor and elongation/flakiness assessment of aggregate is carried out as per IS 2386 (Part I), supporting particle-shape acceptance checks for road and concrete aggregate across India.

Related Products & Category

Part of Tvet Equipments' Aggregate & Rock Testing Equipments range, used alongside the Grid Sieves Set. See also Elongation - Length Gauge.

Frequently Asked Questions

Q1. What does the Aggregate Shape Gauge measure?
It measures the shape factor of aggregate particles.

Q2. What is the scale sensitivity?
0.05 mm, with a tolerance/limit of ±0.05.

Q3. Which standard applies?
IS 2386 (Part I).

Request a Quote

To get a quotation for the Aggregate Shape Gauge, tell us the test standard you work to, the quantity and the delivery location. Request a quote from Tvet Equipments.
