Mortar Compression & Flexural Test Machine Manufacturer,Supplier and Exporter in India

Product Code : TVT-CMTE-10379
Tvet Equipments is a leading Mortar Compression & Flexural Test Machine Manufacturer,and suppliers in India,

Mortar Compression & Flexural Test

The advanced and user-friendly computer software enables results to be acquired automatically with the test curve display and result database being saved virtually unlimited inside the computer.

Suitable for testing on flexural and compression of 40 x 40 x160 mm mortar prism and compression of 50 mm mortar cubes.

This machine is designed for flexural & compression test of cement mortar equipped with two loading frames with two independent measuring ranges for better and consistent performance.

Its fully automatic computer controlled provides constant loading rate for both compression and flexural test.

Software Super Test 7.2

Unlimited saving of test results

Test report can be printed immediately after rest

User friendly to run the operation

Real time display of load

Technical Specifications :

Type of Mode	Compression	Flexural
Max.Capacity	300 kN	15 kN
Piston Stroke	125 mm	60 mm
Speed Control Range	0 ~ 10 kN/s	0 ~ 750 N/s
Vertical Clearance	280 mm	210 mm
Fixed Top Compression Platen	Ø 98 mm	Ø 88 mm
Fixed Bottom Compression Platen	Ø 125	Ø 120
Speed Control Accuracy	≤ ±0.1 %	≤ ±0.5 %
Load Accuracy	±1.0 %
Resolution	0.01 kN	0.1 N
Overall Dimensions (mm)	650(W) x 1400 (L) x 1460 (H)
Power	240 V, 750 W, 1 ph, 50/60 Hz
Approx. Weight	460 kg
